HIFLO-Automatic nozzle DN 25 (1″)
Flow rate up to 140 litres/min.
Working pressure 0,5 – 3,5 bar
With stronger main valve spring up to 5 bar *).
For gasoline, diesel, fuel oil, petroleum, Avgas and Jet-A1. Not suitable for viscous oils and water (corrosion).

STANDARD SPECIFICATION:
-Patented venturi type automatic shut-off with safety cut-out attitude valve.
-Built-in check valve.
-3-speed lever latch with removable latch pin EB 280.
-Swivel hose inlet DN 25 with pressure flushing.
-Screen EK 372 (25 mesh).
-Black cover of soft PVC.
-Body and spout of aluminium.
-Guard of composite material or aluminium.
-Internal parts of stainless steel, bronze and acetal resin.
-Swivel parts of hot stamped brass.
-Steel parts galvanized and chromated.
-Seals of NBR/polyurethane.
-Weight 1,5 kg

Can be ordered with another configuration. Contact for more information.

Elaflex ZVA 25 catalogue and spares
